Filtering and splitting are disabled for custom metrics in metric explorer

Hi ,

Thanks for reaching out to Microsoft Q&A.

The reason why filtering and splitting are disabled for your custom metric (numUsed) in Azure Metrics Explorer is likely due to how custom metrics are structured and ingested into Application Insights. Here’s what’s happening and how to resolve it:

Understanding Why Filtering/Splitting is Disabled

Custom Metrics in Metrics Explorer Need Dimensions

• Azure Metrics Explorer supports filtering and splitting only if the custom metric is ingested with dimensions at the time of tracking.
  • A custom dimension (like computerName) added via TelemetryClient.Context.Properties is only available in Log Analytics, not as a native metric dimension.
  Common Properties vs. Metric Dimensions

  - When you add `computerName` as a common property, it does not make it a first-class metric dimension.

     - Metrics Explorer can only filter/split on dimensions that were included when tracking the metric.


Solution: Send computerName as a Dimension

To allow filtering/splitting in Metrics Explorer, you need to send computerName as a dimension when tracking the metric.

Step 1: Modify How You Send the Metric

Instead of using TelemetryClient.TrackMetric(name, value), use MetricIdentifier and dimensions.

Step 2: Validate in Metrics Explorer

• Wait for 5-10 minutes after deployment.
• Go to Azure Portal > Application Insights > Metrics Explorer.
• Select the numUsed metric and check if computerName appears under "Split By".

Alternative: Use KQL (If You Stick With Logs)

If you want to continue using KQL, you can achieve similar results with this query:

customMetrics | where name == "numUsed" | extend instanceId = tostring(customDimensions["computerName"]) | summarize avg(numUsed) by bin(timestamp, 1m), instanceId | render timechart

Note:

1. If the metric appears in Log Analytics with computerName but not in Metrics Explorer, it means computerName was not sent as a metric dimension.
2. Once sent correctly, filtering and splitting in Metrics Explorer should work without needing KQL.
